Practice EKG Rhythm Strips 207

Identify the following rhythms.


1.


2.


3.


4.


5.













Answers


1.
Bradycardia with a 1st degree AV block













The rhythm is regular with a rate of 55/min.   The P waves are uniform, upright, and have a corresponding QRS complex.   The PR interval is prolonged.   No ectopic beats are noted.   PR:  .32 sec,  QRS:  .10 sec,  QT:  .40 sec.


2.
Normal sinus rhythm












The rhythm is regular with a heart rate of 79/min.   The P waves are positive and uniform.   No ectopic beats are seen.   PR:  .16 sec,  QRS:  .12 sec,  QT:  .40 sec.


3.
Sinus rhythm with artifact













The rhythm looks regular.  There is artifact which obscures the P waves.   The artifact may be due to a loose lead or movement by the patient.


4.
Sinus rhythm with bigeminal PACs













The rhythm is irregular due to the PACs.    The heart rate is 70/min.   The P waves of the PACs have a different shape than the P waves of sinus origin.   The PACs also have a bigeminal pattern occurring every other beat.   PR:  .16 sec,  QRS:  .12 sec,  QT:  .40 sec


5.
Normal sinus rhythm with unifocal PVCs
















The rhythm is irregular  with a rate of 90/min.   The P waves are uniform and upright with a corresponding QRS complex.   There are unifocal PVCs present.   PR:  .20 sec,  QRS:  .08 sec.  QT:  .40 sec.
